<div style="display:none">fjrigjwwe9r4product:pagetitle</div>16ch HDSDI splitter korea

- Displaying high resolution pictures and rapid image processing

by the SOC chip

- Displaying video from at real time

- Auto sequence mode

-When it detects any motion, it changes to auto sequence mode

and ring the alarm

- Supporting NTSC & PAL system

- Displaying the date and time, the name of the channel and the

current status

- RS-232C/RS-485 Communication port for external devices

- Various mode of screen split

MODEL		SV-09HDS	SV-16HDS
Video Input		BNC-F(75Ω 1Vp-p) x 9	BNC-F(75Ω 1Vp-p) x 16
Video Output		BNC-F (Looped through output / 75Ω 1Vp-p) x 9	BNC-F (Looped through output / 75Ω 1Vp-p) x 16
		HDMI x 1, D-Sub x 1, BNC x 2
Video Resolution	HDMI	Full HD:1920x1080p@50/60Hz
		HD:1920x1080i@50/60Hz
		WSXGA:1680x1050@50/60Hz
		SXGA:1280x1024@50/60Hz
	D-SUB	SXGA, WSXGA
	BNC-F	(Monitor)720x480@50/60Hz
Video Format		NTSC/PAL Selectable
Screen Split Mode		1,4,6,7,8,9	1,4,6,7,8,9,10,12,13,16
OSD		Up to 9 Characters (Number/Alphabet)
External Interface	IR Receiver	Remote Control
	4Pin Mini Din	Mouse
	RJ-45	Firmware Upgrade
	RS-232C /RS-485	External device connection
	Alarm I/O	SV-16AIU (Optional)
Power		AC 100~240V, 50/60Hz
Power Consumption		7.5W	8.2W
Temperature/Humidity		0°C~+50°C / 0~80%
Casebody/Weight		Steel / 3.7Kg	Steel / 4Kg
Dimension(mm)		430(W)x44(H)x350(D)	430(W)x44(H)x350(D)


MODEL		SV-16AUI
Alarm Input		Normal Open Type
Alarm Output		Photo Mos Relay
Signal trans. Distance		Max. 10m(RS-232)
Remote Control	Comm. Mode	RS-232
	Port	9Pin D-SUB
	Baud rate	9600bps
Power Input		AC 100~240V, 50/60Hz
Temperature/Humidity		0°C~+50°C / 0~80%
Casebody/Weight		Aluminum / 200g
Dimension(mm)		67(W)x108(H)x21(D)
